Cone Crusher Socket Sealing Ring

TC84X1502A

6359-4701

6380-2381

6360-1743

6380-5101

K1432.2-6

2213-4463

Operational Pain Point & Engineered Solution

The Operational Pain Point

During intensive secondary and tertiary crushing operations, standard off-the-shelf socket sealing rings frequently suffer from thermal hardening, chemical degradation from hot lube oils, and localized tearing caused by harsh abrasive dust penetration. When a generic seal fails unexpectedly, fine rock dust invades the socket cavity, contaminating the hydraulic/lube oil circuit and rapidly grinding down expensive socket liners and spherical bearings. This leads to emergency equipment shutoffs, costly component replacements, and massive daily production losses for mine and quarry operators.

The ZHUOYUE Engineered Solution

ZHUOYUE eliminates premature sealing failure by delivering high-performance, application-tailored replacement socket sealing rings designed specifically for heavy-duty crushing conditions. Instead of supplying generic market rubber, our engineering team selects advanced high-resilience elastomers—such as heat-resistant Nitrile (NBR), ultra-wear-resistant Polyurethane (PU), or high-temperature Viton (FKM)—matched directly to your operating environment. Each sealing ring is manufactured with optimized cross-sectional lips and tight dimensional tolerances. By stopping microscopic abrasives from entering the socket cavity, ZHUOYUE extends lubrication system life, protects internal drive components, and keeps your crushing line running without unexpected downtime.

Reverse Engineering Protocol for Custom / Obsolete Seals

Don't have the original OEM CAD drawing or active part number? We provide a streamlined 3-step solution to ensure zero-risk custom fitting:

Dimensional Sketch or Worn Sample Photos: Provide high-resolution photos with caliper measurements of your worn socket seal or mating housing.

3D CAD Reconstruction: Our dedicated technical team reconstructs the original geometric profile within 48 hours, compensating for operational wear and distortion.

Drawing Approval: We generate 2D/3D manufacturing drawings for your final sign-off before production begins.

Technical Specifications Matrix

Cross-Reference OEM Compatibility Guide (For Reference Only)

Key Advantages

Engineered Elastomer Formulations: Polymer compounds tailored specifically for high oil resistance, anti-friction behavior, and high-temperature tolerance to avoid premature brittleness.

Precision Cross-Sectional Fit: Machined and molded to tight structural tolerances (±0.08mm), eliminating clearance gaps that allow dust penetration or oil seepage.

Extended Service Life: High wear resistance reduces replacement frequencies, minimizing wear on mating socket surfaces and journal bearings.

Versatile Customization: Full capability to produce specialized geometries, oversized profiles, or discontinued legacy seals where original OEM parts are unavailable.

Primary Applications

Hard Rock Mining Operations: Installed in primary, secondary, and tertiary cone crushers processing high-abrasion ores such as iron, copper, gold, and quartz.

Aggregate & Quarry Production: Applied in high-capacity aggregate plants producing concrete rock, gravel, and manufactured sand under heavy dust exposure.

Demolition & Recycled Material Processing: Operates efficiently in mobile and stationary plants handling variable feed materials and harsh environmental swings.

Equipment Overhaul & Remanufacturing: Serves as high-reliability replacement seals for mining equipment repair centers and field service crews.

About Us

Shenyang Zhuoyue focuses on mining machinery and crusher replacement parts, with a core team bringing more than 10 years of industry experience.

· 10 machining lines

· 2 welding lines

· 2 assembly lines

· 24 R&D and technical personnel

Approximately 2,000 tons of annual production capacity

The team covers process confirmation, manufacturing and quality inspection for crusher components, wear parts and customized machined parts.

For replacement components, production can be organized around confirmed technical information such as crusher models, OEM part numbers, drawings, samples and measurements.

Manufacturing & Technical Strengths

Specialized Engineering Leadership: Over 10 years of specialized experience in heavy mining machinery, crusher wear parts, and custom elastomeric sealing solutions.

Dedicated Technical Team: In-house technical engineering support capable of complex reverse engineering, CAD verification, and custom material adaptation.

Integrated Precision Manufacturing: Advanced precision CNC machining, elastomer molding lines, and strict component assembly inspection.

Global Supply Footprint: Established export network supplying mine operators, contractors, and machinery distributors across global markets.

Quality Inspection Standards & Material Traceability

Each batch of oil separator rings is inspected against the approved technical drawings, specified material grade, applicable international standards, and customer acceptance requirements. Inspection records can be provided for quality verification and traceability.

Raw Material & Batch Verification

Each material batch is verified before production. Tensile strength, elongation at break, tear resistance, and oil resistance are tested according to the specified elastomer grade and applicable standards, such as ISO 37 for tensile properties and ISO 34-1 for tear strength. Oil resistance is evaluated according to the applicable rubber testing specification, such as ISO 1817, when required.

Material Test Report (MTR)

Material and physical-property test results can be supplied with the shipment for traceability. Where specified, documentation can include an EN 10204 3.1 Material Test Certificate (MTC) together with the applicable physical-property test report.

100% Dimensional & Lip Profile Inspection

Critical inner diameter, outer diameter, groove dimensions, and sealing-lip profiles are inspected 100% using optical measuring equipment, digital calipers, and other calibrated instruments. Results are checked against the approved engineering drawing, specified dimensional tolerances, and applicable ISO 286 fit requirements where relevant.

Hardness & Elasticity Testing

Shore A hardness is verified according to ISO 48-4 / ASTM D2240, using the hardness range specified for the selected elastomer compound. Where required, elasticity or compression-related properties are evaluated according to the applicable material specification and customer requirements.

Fitment Verification & Sample Orders

Low-MOQ or single-piece sample orders are supported for fitment verification before bulk production. The supplied sample can be checked against the customer's crusher model, OEM part number, drawing, or existing component to confirm critical dimensions and sealing interface requirements.

Anti-Aging Packaging & Storage Guidelines

Export-Grade UV Protective Packaging: Individual UV-barrier sealed bags with internal shape-retention supports prevent elastomeric deformation during long transit times.

Maritime & Tropical Protection: Packed in reinforced, moisture-sealed wooden cases to prevent oxidation, thermal degradation, or ocean-freight distortion.

Recommended Storage Shelf-Life: Stored in a cool, dark, and dry environment (< 25°C), our sealed elastomeric rings retain optimal elasticity for 5 years (NBR/PU) to 10 years (FKM).

Frequently Asked Questions (FAQ)

Q1: How do you ensure precision fitment for legacy, obsolete, or modified cone crushers?

Before manufacturing, our technical engineering team performs rigorous pre-production checks. We verify supplied equipment model numbers, OEM codes, CAD drawings, physical worn samples, or dimensional sketches to build a precise 3D CAD model and guarantee exact tolerance compatibility.

Q2: Which rubber or polymer material should I choose for my specific crushing environment?

We recommend NBR for standard lube oil and dust protection, Polyurethane (PU) for high-abrasion crushed rock environments, and FKM (Viton) for continuous high-temperature crushing setups. Our technical engineers will review your working conditions and recommend the optimal formulation.

Q3: What is the Minimum Order Quantity (MOQ) and production lead time?

MOQ starts from 1 piece for emergency replacements and trial orders. Standard lead time is 25–30 days for scheduled overhauls. Emergency orders can be expedited for air dispatch within 10–15 days.

Q4: How does ZHUOYUE handle quality warranty claims?

All socket sealing rings come backed by a full 12-Month Quality Warranty. In the rare event of a dimensional mismatch or material defect under normal operating conditions, our engineering team provides immediate failure analysis and dispatches expedited replacement parts at zero product cost.

Q5: Can you manufacture replacement seals if the original OEM part number is unknown?

Yes. You can send photos with key caliper measurements or send physical worn samples directly to our engineering team. We utilize reverse engineering to model exact original specifications and manufacture fully compatible replacement sealing components.
