Cone Crusher Gear

When replacing cone crusher gears, buyers may face difficulties when original drawings or complete technical information are unavailable. A gear that only matches basic dimensions may still fail to achieve proper engagement if tooth number, module, tooth profile or mating gear parameters are different, which may lead to unstable transmission, increased vibration and premature wear.

Shenyang Zhuoyue reviews crusher models, reference part numbers, drawings, samples, photos and measurements before production to confirm the required gear configuration. Through ISO 6-grade precision machining, ±0.008mm tooth profile variation control and 0.01mm tooth runout control, Shenyang Zhuoyue manufactures replacement gears with accurate tooth geometry and reliable transmission performance.

Product Advantages

1. High-Precision Tooth Profile Design for Stable Transmission

Cone crusher gears require accurate tooth geometry to ensure proper engagement with mating gears. Incorrect tooth parameters may cause unstable transmission and increased wear.

Shenyang Zhuoyue applies ISO 6-grade precision machining and optimized tooth profile design. The tooth profile variation is controlled within ±0.008mm, achieving 92%+ contact area during gear engagement and improving transmission stability.

2. High-Strength Material and Heat Treatment for Heavy Loads

Cone crusher gears operate under continuous impact and heavy loads in mining environments. Insufficient hardness or poor toughness may accelerate tooth wear.

Shenyang Zhuoyue uses 20CrMnTi alloy steel with vacuum carburizing heat treatment.

After treatment:

· Surface hardness: HRC58–62

· Core hardness: HRC32–38

The gear supports 10 million turns of alternating torque operation, with wear reduced by 42% and service life improved by 45% compared with regular cast gears.

3. Controlled Manufacturing and Customized Replacement Support

Replacement gears need to match the original crusher transmission system accurately.

Shenyang Zhuoyue manufactures gears according to:

· Drawings

· OEM/reference part numbers

· Gear samples

· Photos and measurements

Through controlled machining, heat treatment and inspection processes, ZHUOYUE maintains 99.8% product qualification rate and 99.5% batch consistency.

Key Specifications

Final specifications are confirmed according to the crusher model, gear design, mating components and customer requirements.

Gear Matching: What Needs to Be Checked?

A replacement gear should not be selected by outside diameter or bore size alone. The tooth geometry and mating gear must also be considered.

Important parameters may include:

· Tooth number

· Module or diametral pitch

· Pressure angle

· Helix angle, where applicable

· Tooth profile

· Pitch and outside diameter

· Bore and keyway dimensions

· Face width

· Mating gear information

These parameters should be checked together because a gear with the correct external dimensions may still be unsuitable if its tooth geometry or mating dimensions are different.

If the original drawing is unavailable, available photos, measurements or an existing gear sample can be reviewed to identify additional information needed for confirmation.

Manufacturing Process & Quality Control

The manufacturing process follows:

Material Preparation → Gear Machining → Heat Treatment → Finishing → Inspection

Shenyang Zhuoyue uses 20CrMnTi alloy steel and applies carburizing, quenching and tempering according to confirmed requirements. Each gear is inspected through dimensional checks, tooth-related inspection, hardness verification, runout checks and visual inspection before delivery.

With controlled manufacturing and inspection processes, Shenyang Zhuoyue achieves 99.8% product qualification rate and 99.5% batch consistency.

Pre-Production Confirmation

Before machining starts, key specifications can be reviewed and confirmed with the buyer, including:

· Gear dimensions

· Tooth parameters

· Bore and keyway dimensions

· Material

· Heat-treatment requirements

· Quantity

· Packaging requirements

This confirmation helps reduce the risk of producing a gear with incorrect dimensions or tooth geometry when the original information is incomplete.

Replacement & Custom Manufacturing

Shenyang Zhuoyue can manufacture aftermarket replacement or non-standard cone crusher gears based on:

· Customer drawings

· OEM or reference part numbers

· Existing gear samples

· Photos and measurements

· Confirmed technical requirements

The product configuration is determined by the supplied technical information rather than assumed from the crusher name alone.

What to Provide for a Quote

For technical review and quotation, please provide as much of the following information as available:

· Crusher brand and model

· OEM or reference part number

· Gear drawing or photos

· Tooth number

· Module or diametral pitch

· Main dimensions

· Bore and keyway dimensions

· Material requirements

· Heat-treatment requirements, if specified

· Order quantity

· Delivery destination, if available

No original drawing? An existing gear sample, photos or available measurements can be provided first. Additional dimensions may be requested if key tooth or mating-gear information cannot be confirmed.

Applications

Cone crusher gears are used in crusher drive systems for:

· Mining and quarrying

· Aggregate production

· Mineral processing

· Construction material processing

The final gear configuration depends on the crusher model, transmission design and mating components.

About Us

Shenyang Zhuoyue Machinery Equipment Co., Ltd. has more than 10 years of experience in mining machinery and crusher replacement components. The company has 24 R&D and technical personnel and provides manufacturing support through machining, welding and assembly capabilities.

With 10 machining lines, 2 welding lines and 2 assembly lines, Shenyang Zhuoyue has established a production system for replacement components with different material, size and processing requirements. The annual production capacity reaches approximately 2,000 tons.

With experience in mining and crushing equipment components, Shenyang Zhuoyue provides manufacturing solutions for replacement parts including transmission-related components, wear parts and other customized requirements.

Packaging & Delivery

Finished gears can be protected against impact and moisture during transportation. Wooden crates or other suitable export packaging can be arranged according to product size and shipping requirements.

Trade Terms: EXW and FOB

Order Quantity: Confirmed according to gear specification, production requirements and customer needs.

Lead Time: Depends on gear size, material, tooth geometry, heat-treatment requirements and order quantity. The delivery schedule is confirmed after the technical requirements are reviewed.

FAQ

Q1: What information is required for a replacement cone crusher gear?

A:Provide the crusher model, gear drawing, part number, dimensions or other available technical information. These details help confirm the required gear specifications before production.

Q2: Can you manufacture a cone crusher gear according to a drawing?

A:Yes. Cone crusher gears can be manufactured according to approved drawings and confirmed technical requirements.

Q3: What if the original gear information is incomplete?

A:Available information such as equipment model, part number, photos or measurements can be reviewed first. Additional details required for production can be confirmed based on the available information.

Q4: How do you control the quality of cone crusher gears?

A:Key manufacturing requirements, including important dimensions and machining specifications, can be inspected according to the confirmed production requirements before delivery.

Q5: Can you produce gears for different cone crusher models?

A:Production can be arranged according to different equipment requirements, drawings and technical specifications. The final production details are confirmed before manufacturing.

Request a Cone Crusher Gear

For a replacement or custom cone crusher gear, send the crusher model, reference part number, available gear specifications and required quantity. Drawings, samples, photos or measurements can be included when available to support technical review and quotation.
